Description
| Pulling Force | 10 kN (2,200 lbs.) |
| Stroke | 25 mm (1″) |
| Rivet Diameter Range | 2.4 – 4.8 mm (3/32″ – 3/16″) |
| Center Height | 26 mm (1″) |
| Work Amount (pcs) | w/ BL1860B: 2,800 w/ BL1850B: 2,300 w/ BL1820(B): 950 |
| Max Output | 360 W |
| Vibration Level | Installing Blind Rivet: 2.5 m/s² or less |
| Vibration K Factor | Installing Blind Rivet: 1.5 m/s² |
| Sound Pressure Level | 75 dB(A) |
| Noise K Factor | 3 dB(A) |
| Dimensions (L × W × H) | w/ BL1815N / BL1820B: 313 × 80 × 270 mm (12-3/8″ × 3-1/8″ × 10-5/8″) w/ BL1830B / BL1840B / BL1850B / BL1860B: 313 × 80 × 287 mm (12-3/8″ × 3-1/8″ × 11-1/4″) |
| Net Weight | 1.9 – 2.2 kg (4.2 – 4.9 lbs.) |
